Reducing Adapters SAE 070123
REDUCING ADAPTERS SAE 070123
| Part No | Tube OD (P-PT) | Tube OD (P-PT) | Dimensions | ||
| inch | mm | inch | mm | L | |
| VE-6J-4J-SS | 3/8 | 10 | 1/4 | 6.00 | 24.60 |
| VE-8J-4J-SS | 1/2 | 12 | 1/4 | 6.00 | 25.40 |
| VE-8J-6J-SS | 1/2 | 12 | 3/8 | 10.00 | 25.40 |
| VE-10J-4J-SS | 5/8 | 16 | 1/4 | 6.00 | 26.20 |
| VE-10J-6J-SS | 5/8 | 16 | 3/8 | 10.00 | 26.20 |
| VE-12J-4J-SS | 3/4 | 18 | 1/4 | 6.00 | 27.70 |
| VE-12J-6J-SS | 3/4 | 18 | 3/8 | 10.00 | 27.70 |
| VE-12J-8J-SS | 3/4 | 18 | 1/2 | 12.00 | 30.20 |
| VE-14J-6J-SS | 7/8 | 22 | 3/8 | 10.00 | 28.70 |
| VE-14J-10J-SS | 7/8 | 22 | 5/8 | 16.00 | 33.70 |
| VE-16J-4J-SS | 1 | 25 | 1/4 | 6.00 | 31.00 |
| VE-16J-6J-SS | 1 | 25 | 3/8 | 10.00 | 31.00 |
| VE-16J-8J-SS | 1 | 25 | 1/2 | 12.00 | 32.30 |
| VE-16J-10J-SS | 1 | 25 | 5/8 | 16.00 | 35.10 |
| VE-16J-12J-SS | 1 | 25 | 3/4 | 18.00 | 37.30 |
| VE-20J-12J-SS | 1 1/4 | 32 | 3/4 | 18.00 | 38.80 |
| VE-20J-16J-SS | 1 1/4 | 32 | 1 | 25.00 | 40.30 |
| VE-24J-8J-SS | 1 1/2 | 38 | 1/2 | 12.00 | 39.60 |
| VE-24J-12J-SS | 1 1/2 | 38 | 3/4 | 18.00 | 41.40 |
| VE-24J-16J-SS | 1 1/2 | 38 | 1 | 25.00 | 41.40 |
| VE-32J-24J-SS | 2 | 50 | 1 1/2 | 38.00 | 48.50 |
